2U 48 Port Fiber Optic Patch Panel Light Fc Simplex Slide Out ODF

Name: 2U 48 Port Fiber Optic Patch Panel Light Fc Simplex Slide Out ODF
Brand: Twilight Optic
Price: 1 USD

Quality 2U 48 Port Fiber Optic Patch Panel Light Fc Simplex Slide Out ODF wholesale

Brand Name : Twilight Optic

Model Number : TW-DR03-2U-FC

Place of Origin : Guangdong

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000pcs per week

Delivery Time : 7-10 working days

Packaging Details : Inner box and carton box,5 pcs/Carton Carton Size : 55*35*34cm G/W: 19KG

Name : Optical Distribution Frame Odf

Adapter : FC,ST,SC,LC

Type : Sliding type

Material : Cold Rolled Steel

Capacity : 48core

Color : Black or White

Dimension : 485*250*90mm

Height : 2U

Contact Now

48 Ports Fc Simplex Slide-Out Optical Distribution Frame Odf 19inch 2u

Description:

Fiber patch panel series of optic distribution boxes ,which are middle capacity and

both side operation applicable in the branch connection of fiber termination ,working

as distribution box.

It is with standard 19 inch size and properly designed to control the bend radius of the

cable inside the enclosure to avoid extra optical loss. This frame is ideal for indoor

fiber optic cables connection storage, distribution and management.

Features:

❖ Standard size, light weight and reasonable structure

❖ Slide out drawer for easy cable management

❖ FC, SC, ST, LC adapter patch panel for option

❖ Front access panel design for easy operation

❖ Suitable for 19’’ or 23’’ standard optic distribution cabinets

❖ With metal front cover

❖ 2-8 pcs splice trays (each 12 fibers)

❖ Max. capacity 48 fibers

❖ 4 fiber cable entry ports at rear side

❖ White or black color

Specification

Model	TW-DR03-2U
Type	19inch Rack Mount
Material	Cold Rolled Steel
Size WDH (mm)	48529547MM
Capacity (core)	48
Included accessories	4pcs cable fix accessories, heat shrink tubes, cable ties, number tapes, adapter screws
Product color	White or black color
Working temperature	-40~+85°C
Storage temperature	-40~+85°C

2U 48 Port Fiber Optic Patch Panel Light Fc Simplex Slide Out ODF

Application:

Telecommunications

Fiber to the home (FTTH)

LAN / WAN

CATV
